87V Capacitor Differential Voltage Protection Relay | Voltage Unbalance Protection for Capacitor Banks

Protection Functions

Three-stage overcurrent protection
Capacitor differential voltage protection
Zero-sequence overvoltage protection
Overvoltage protection with no-current blocking option
Undervoltage protection with current blocking option
Phase-to-ground overvoltage protection with no-current blocking, judged by phase voltage
Phase-to-ground undervoltage protection with current blocking, judged by phase voltage

Communication Mode:Optional: RS-485, CAN bus, Ethernet, IEC 60870-5-103 ,IEC61850

Download datasheet (PDF)

Send your requirements, we will quote for you within 12 hours​
MOQ: 1 setLead time: 7-15 working daysPayment: T/T, L/C, Western Union, PayPalWarranty: 12 monthsTrade terms: EXW, FOB, CIF, DDUCertification: CEDifferent rating, protocol or mounting: send the specification and we confirm before you order.

Description

What is an 87V capacitor differential voltage protection relay?

An 87V relay protects a shunt capacitor bank by measuring the voltage unbalance between the two halves of a split-phase bank, or between the bank neutral and earth, and tripping when the unbalance exceeds a setting. The element is a voltage differential rather than a current differential because the failure mode it targets is a few elements shorted inside one can, which moves the neutral point without producing a current large enough for an overcurrent relay to see. Catching that early is what prevents the remaining elements from cascading, which is how a bank goes from a small defect to a ruptured case. Settings are calculated from the bank configuration, the number of series and parallel elements, and the reactor tuning. Typical duty is a 10 kV or 35 kV compensation bank. Bank data review at order; quotation within 12 hours, MOQ 1, 7-15 working days.

Overview of Capacitor Differential Voltage Protection Relay

  • The ASC-447H Digital Capacitor Differential Voltage Protection Unit applies to medium and low voltage shunt capacitor banks.

Protection Functions

  • Three-stage overcurrent protection
  • Capacitor differential voltage protection
  • Zero-sequence overvoltage protection
  • Overvoltage protection with no-current blocking option
  • Undervoltage protection with current blocking option
  • Phase-to-ground overvoltage protection with no-current blocking, judged by phase voltage
  • Phase-to-ground undervoltage protection with current blocking, judged by phase voltage

Communication Functions

  • Three communication modes available: RS-485, CANBUS and Ethernet. Please specify when placing orders.
  • Upload real-time data including measurement data, fault recording data, fault and alarm signals, protection settings, configuration and parameters. Remote online setting modification and protection switching are supported.
  • Receive upper commands for remote control, time synchronization, setting adjustment and data read-write.

Control Cabinet Functions

  • Built-in anti-tripping control circuit
  • Adaptive closing and tripping current

Self-diagnosis Functions

  • Automatic fault detection of RAM, ROM, A/D module and power loss
  • Automatic verification of settings, configuration and parameters
  • Event Record & Fault Recording
  • Record protection trips and device abnormalities
  • Log protection type, operating time and operating parameters during trips
  • Record trip time, protection type and effective values before and after faults
  • Waveform storage: 2 cycles before fault and 4 cycles after fault per channel
  • 48 groups of SOE records and 16 groups of fault reports can be retained after power loss

Monitoring Functions

  • Measure analog quantities such as current, voltage and frequency
  • Collect status signals of circuit breaker, energy storage, isolating switch and local/remote mode
  • Circuit breaker closing and tripping control

Display Functions

  • Chinese LCD screen, status indicators and operation keypad equipped. Support real-time monitoring, online setting modification and protection switching. Fault indicators can be reset locally or remotely.

Setting List of Capacitor Bank Unbalance Voltage Protection(59NU/59N)

No.Display NameRangeStepRemark
1Stage 1 Protection Setting
1.1Stage 1 Protection Switch1/01: Enable, 0: Disable Stage 1 Overcurrent Protection
1.2Stage 1 Time Delay0-120.00s0.01s
1.3Stage 1 Setting Value0.40-99.99A0.10-20.00A0.01ARated Current In=5ARated Current In=1A
2Stage 2 Protection Setting
2.1Stage 2 Protection Switch1/01: Enable, 0: Disable Stage 2 Overcurrent Protection
2.2Stage 2 Time Delay0-120.00s0.01s
2.3Stage 2 Setting Value0.40-99.99A0.10-20.00A0.01AIn=5AIn=1A
3Stage 3 Protection Setting
3.1Stage 3 Protection Switch1/01: Enable, 0: Disable Stage 3 Overcurrent Protection
3.2Stage 3 Time Delay0-120.00s0.01s
3.3Stage 3 Setting Value0.40-99.99A0.10-20.00A0.01AIn=5AIn=1A
4Overvoltage Protection Setting
4.1Overvoltage Protection Switch1/01: Enable, 0: Disable Overvoltage Protection
4.2Overvoltage Time Delay0-120.00s0.01s
4.3Overvoltage Setting Value5-120.00V0.01V
5Undervoltage Protection Setting
5.1Undervoltage Protection Switch1/01: Enable, 0: Disable Undervoltage Protection
5.2Undervoltage Time Delay0-120.00s0.01s
5.3Undervoltage Setting Value5-100.00V0.01V
6Differential Voltage Protection Setting
6.1Differential Voltage Protection Switch1/01: Enable, 0: Disable Differential Voltage Protection
6.2Differential Voltage Time Delay0-120.00s0.01s
6.3Differential Voltage Setting Value0.5-25V0.01V
7Zero-sequence Overvoltage Setting
7.1Zero-sequence Overvoltage Protection Switch1/01: Enable, 0: Disable Zero-sequence Voltage Protection
7.2Zero Voltage Time Delay0-120.00s0.01s
7.3Zero Voltage Setting Value5-120.00V0.01V
8Phase-to-ground Undervoltage Setting
8.1Phase-to-ground Undervoltage Switch1/01: Enable, 0: Disable Phase-to-ground Undervoltage Protection
8.2Undervoltage Time Delay0-120.00s0.01s
8.3Undervoltage Setting Value5-70.00V0.01V
9Phase-to-ground Overvoltage Setting
9.1Phase-to-ground Overvoltage Switch1/01: Enable, 0: Disable Phase-to-ground Overvoltage Protection
9.2Overvoltage Time Delay0-120.00s0.01s
9.3Overvoltage Setting Value5-70.00V0.01V
10General Setting
10.1Bus PT Broken Line Detection1/01: Enable, 0: Disable
10.2Control Circuit Broken Line Detection1/01: Enable, 0: Disable
10.3Current Blocking Over & Under Voltage1/01: Enable, 0: Disable
10.41A Rated Current Selection0.1-99.99A0.01A1: 1A rated, 0: 5A rated
10.5Current Blocking Setting0.1-99.99A0.01ACurrent blocking threshold value

Outline and Installation Dimensions

AST-441H transformer differential protection relay front panel AST-441H relay rear terminal arrangement Line distance protection relay enclosure Panel cut-out dimension drawing for the 441H series relay

FAQ

Q:How does capacitor differential voltage protection work?

A:It detects unbalanced voltage difference across capacitor banks and trips promptly once exceeding threshold to isolate faulty capacitors.

Q:What is the installation mode of capacitor differential voltage protection device?

A:The capacitor differential voltage protection device is generally mounted on switchgear or assembled into panels per project requirements.

Q: What is Capacitor Differential Voltage Protection?

A: It is a dedicated protection for capacitor banks. It monitors the voltage difference between two capacitor branches. When internal series capacitor elements break down and short-circuit, the voltage imbalance triggers tripping to prevent capacitor overvoltage burst and fire hazards.

Q: How does differential voltage protection work?

A: Two groups of series capacitors form two parallel branches. Voltage transformers extract branch voltages and send signals to the relay. Once the voltage deviation exceeds the fixed threshold, the protection judges an internal fault and trips the circuit breaker.

Q: Where is this protection applied?

A: Mainly for high-voltage shunt capacitor banks with multi-series sections, used in substation reactive power compensation cabinets and power factor correction devices.

Q: Why adopt differential voltage instead of overcurrent protection only?

A: Overcurrent protection cannot detect early single element breakdown inside the capacitor string. Differential voltage protection catches slight voltage unbalance at the initial fault stage with high sensitivity, avoiding cascading breakdown of the entire capacitor group.

Q: What are the key principles for setting the differential voltage threshold?

A: The pickup value must be higher than normal unbalanced voltage caused by manufacturing tolerance and ambient temperature; meanwhile it shall be lower than the dangerous overvoltage that damages remaining healthy capacitors. A short time delay is added to block transient fluctuation misoperation.

Q: What are the mandatory PT wiring rules?

A: Voltage transformers must be strictly matched for two branches with same ratio; PT secondary circuits cannot be open-circuited. Each PT secondary side shall be reliably grounded at one point only.

Q: What happens if PT polarity is reversed?

A: The calculated differential voltage is abnormal, leading to constant protection alarm or incorrect tripping under normal operation. Polarity inspection is required during commissioning.

Q: Why does the protection misoperate without an actual capacitor fault?

A: Common causes: PT wiring loose/reversed, inconsistent PT accuracy, serious three-phase system voltage unbalance, harmonic distortion. Solutions: check wiring, calibrate PT, increase proper delay.

Q: Why does the protection fail to trip during a capacitor internal fault?

A: Possible reasons: setting value too large, PT secondary open circuit, signal cable breakage, relay channel failure. Inspect loop continuity and recheck protection parameters.

Q: Why does tripping occur after the capacitor bank is switched on?

A: Inrush voltage transient causes momentary imbalance. Enable inrush blocking function or extend short delay to avoid malfunction.

Q: Can it work with other capacitor protections?

A: Yes. It is normally used together with overcurrent protection, zero-sequence earth fault protection and overvoltage protection as a complete protection scheme for capacitor banks.

Q: What routine inspection items are required?

A: Regularly check PT insulation and wiring tightness; test differential voltage reading under no-load state; back up protection setting values; clean dust on voltage acquisition terminals.
